Tecnología ambiental: agua, aguas residuales y reciclaje



Los productos de BD|SENSORS también tienen una demanda cada vez mayor en el sector de la industria agroalimentaria. En la administración local e industrial de los recursos hídricos se utilizan sensores de presión electrónicos para medir los niveles de llenado, por ejemplo. En este caso los materiales deben cumplir ciertos requisitos especiales. Han de ser resistentes frente a los medios corrosivos y a la carga mecánica.



Los transmisores de presión y los dispositivos de medición del nivel de BD|SENSORS cumplen estos requisitos gracias a la introducción de sensores seleccionados de un modo específico, a los materiales robustos para la carcasa (PP, PVC, PVDF, acero fino, etc.) y a los materiales empleados para cables y juntas.

La experiencia de muchos años en el ámbito de la tecnología ambiental y el hecho de contar con empleados altamente cualificados permiten que podamos formalizar los pedidos de los clientes de una manera óptima. El equipo de asistencia de ventas técnicas le asesora minuciosamente y le apoya al elegir el aparato que mejor se adapte a su situación individual con respecto a la medición.

Productos de BD|SENSORS para la tecnología ambiental

Puede encontrar el sensor perfecto para sus necesidades con tan solo algún que otro clic. Seleccione el tipo de sensor y/o el medio:

sensor / diaphragm: reset selection

BAROLI 02

stainless steel sensor
laboratory, environmental industry
  • nominal pressure:0 ... 100 mbar up to 0 ... 600 bar
  • accuracy:0.125 % FSO BFSL (class 0.1)
  • certificates: CE

BAROLI 05

ceramic sensor
laboratory, environmental industry
  • nominal pressure:0 ... 400 mbar up to 0 ... 600 bar
  • accuracy:0.25 % FSO BFSL (class 0.2)
  • certificates: CE

DM 10

ceramic sensor
plant and mechanical engineering
  • nominal pressure:0 ... 1,6 bar up to 0 ... 250 bar
  • accuracy:0.5 % FSO BFSL (class 0.5)
  • certificates: CE UL
Industrial Pressure Transmitter with Ceramic Sensor; oxygen application; pressure port G 1/2"

DMK 331

ceramic sensor
universal applications
  • nominal pressure:0 ... 400 mbar up to 0 ... 600 bar
  • accuracy:0.5 % FSO
  • certificates: CE Ex IECEX SIL UL
Pressure Transmitter with Ceramic Sensor; capacitive sensor; high media resistance

DMK 351

ceramic sensor
laboratory techniques, biogas plants
  • nominal pressure:0 ... 40 mbar up to 0 ... 20 bar
  • accuracy:0,25 % / 0.35 % FSO
  • certificates: CE Ex UL
Industrial Pressure Transmitter

DMP 321

stainless steel sensor
universal application
  • nominal pressure:0 ... 100 mbar up to 0 ... 600 bar
  • accuracy:0,1 % / 0,25 % FSO
  • certificates: CE Ex IECEX UL
Industrial Pressure Transmitter for Low Pressure with Stainless Steel Sensor;

DMP 331

stainless steel sensor
universal applications
  • nominal pressure:0 ... 100 mbar up to 0 ... 60 bar
  • accuracy:0,1 / 0,25 / 0,35 %
  • certificates: CE Ex IECEX SIL UL

DPT 100

stainless steel sensor
test engineering, machine and plant engineering
  • differential pressurefrom10 mbar up to 20 bar
  • accuracy:0,1 % FSO
  • certificates: CE
Process Pressure Transmitter with HART-communication

XMP ci

ceramic sensor
process, oil and gas industry
  • nominal pressure:0 ... 160 mbar up to 0 ... 20 bar
  • accuracy:0,1 % FSO
  • certificates: CE HART Ex

LMK 306

ceramic sensor
stainless steel probe Ø 17
  • nominal pressure:0 ... 6 mH2O up to 0 ... 200 mH2O
  • accuracy:0.5 % FSO
  • certificates: CE

LMK 307

ceramic sensor
stainless steel probe Ø 27
  • nominal pressure:0 ... 4 mH2O up to 0 ... 250 mH2O
  • accuracy:0.5 % FSO
  • certificates: CE Ex IECEX SIL
Level and Temperature Transmitter

LMK 307 T

ceramic sensor, flush
Level and Temperature Transmitter
  • nominal pressure:from 0 ... 4 mH2O up to 0 ... 250 mH2O
  • accuracy:0,5 % FSO
  • certificates: CE

LMK 331

ceramic sensor, flush
plant and mechanical engineering
  • nominal pressure:0 ... 400 mbar up to 0 ... 60 bar
  • accuracy:0.5 % FSO
  • certificates: CE Ex IECEX SIL UL

LMK 351

ceramic sensor, flush
environmental industry, renewable energy
  • nominal pressure:0 ... 40 mbar up to 0 ... 20 bar
  • accuracy:0.25 % / 0.35 % FSO
  • certificates: CE Ex UL

LMK 358

ceramic sensor
separable stainless steel probe Ø 39,5
  • nominal pressure:0 ... 40 cmH2O up to 0 ... 100 mH2O
  • accuracy:0,25 % / 0.35 % FSO
  • certificates: CE Ex

LMK 358 H

ceramic sensor
seperable stainless steel probe Ø 39,5
  • nominal pressure range0 ... 60 cmH2O up to 0 ... 100 mH2O
  • accuracy:0.1 %
  • certificates: CE Ex HART

LMK 382

ceramic sensor
stainless steel probe Ø 39,5
  • nominal pressure:0 ... 40 cmH2O up to 0 ... 100 mH2O
  • accuracy:0,25 % / 0.35 % FSO
  • certificates: CE Ex

LMK 382 H

ceramic sensor
steel probe Ø 39,5
  • nominal pressure range0 ... 60 cmH2O up to 0 ... 100 mH2O
  • accuracy:0.1 % / 0.2 % FSO
  • certificates: CE HART Ex
Stainless Steel Probe 22 mm

LMK 387

ceramic sensor, flush
Stainless Steel Probe 22 mm
  • nominal pressure:from 0 ... 4 mH2O up to 0 ... 100 mH2O
  • accuracy:0,35 % FSO
  • certificates: CE Ex
Plastic Probe for Aggressive Media

LMK 806

ceramic sensor, flush
Plastic Probe Ø 21
  • nominal pressure:from 0 ... 6 mH2O up to 0 ... 200 mH2O
  • accuracy:0,5% FSO
  • certificates: CE

LMK 807

ceramic sensor
plastic submersible probe Ø 35
  • nominal pressure:0 ... 4 mH2O up to 0 ... 100 mH2O
  • accuracy:0.5 % FSO
  • certificates: CE SIL

LMK 809

ceramic sensor
plastic probe Ø 45
  • nominal pressure:0 ... 40 cmH2O up to 0 ... 100 mH2O
  • accuracy:0,25 % / 0.35 % FSO
  • certificates: CE

LMK 858

ceramic sensor
separable plastic submersible probe Ø 45
  • nominal pressure:0 ... 40 cmH2O up to 0 ... 100 mH2O
  • accuracy:0.25 % / 0.35 % FSO
  • certificates: CE

LMP 305

stainless steel sensor
slimline-probe Ø 19
  • nominal pressure:0 ... 1 mH2O up to 0 ... 250 mH2O
  • accuracy:0.25 % / 0.35 % FSO
  • certificates: CE

LMP 307

stainless steel sensor
stainless steel probe Ø 27
  • nominal pressure:0 ... 1 mH2O up to 0 ... 250 mH2O
  • accuracy:0,1 % / 0,25 % / 0.35 % FSO
  • certificates: CE Ex IECEX SIL

LMP 307i

stainless steel sensor
stainless steel probe Ø 26.5
  • nominal pressure:0 ... 4 mH2O up to 0 ... 200 mH2O
  • accuracy:0.1 % FSO
  • certificates: CE Ex IECEX

LMP 307T

stainless steel sensor
stainless steel probe Ø
  • nominal pressure:0 ... 1 mH2O up to 0 ... 250 mH2O
  • accuracy:0,25 % / 0,35 % FSO
  • certificates: CE

LMP 308

stainless steel sensor
separable stainless steel probe Ø 35
  • nominal pressure:0 ... 1 mH2O up to 0 ... 250 mH2O
  • accuracy:0,1 % / 0,25 % / 0.35 % FSO
  • certificates: CE Ex IECEX SIL

LMP 308 i

stainless steel sensor
seperable stainless steel probe Ø 35
  • nominal pressure:0 ...4 mH2O up to 0...200 mH2O
  • accuracy:0.1 % FSO
  • certificates: CE Ex IECEX

LMP 331

stainless steel sensor
plant and mechanical engineering
  • nominal pressure:0 ... 100 mbar up to 0 ... 40 bar
  • accuracy:0,1 % / 0,25 % / 0.35 % FSO
  • certificates: CE Ex IECEX SIL UL
precision pressure transmitter with M12x1 connector and G1/2" pressure port

LMP 331i

stainless steel sensor
laboratory, environmental industry
  • nominal pressure:0 ... 400 mbar up to 0 ... 40 bar
  • accuracy:0.1 % FSO
  • certificates: CE Ex IECEX

LMP 808

stainless steel sensor
separable plastic probe Ø 35
  • nominal pressure:0 ... 1 mH2O up to 0 ... 100 mH2O
  • accuracy:0,25 % / 0.35 % FSO
  • certificates: CE SIL

DS 200

stainless steel sensor
universal applications
  • nominal pressure:0 ... 100 mbar up to 0 ... 600 bar
  • accuracy:0.25 % / 0.35 % FSO
  • certificates: CE Ex

DS 201

ceramic sensor
universal applications
  • nominal pressure:0 ... 400 mbar up to 0 ... 600 bar
  • accuracy:0.5 % FSO
  • certificates: CE Ex

DS 400

stainless steel sensor
Hygienic Design
  • nominal pressure:0 ... 100 mbar up to 0 ... 600 bar
  • accuracy:0.25 % / 0.35 % FSO
  • certificates: CE Ex

DS 401

ceramic sensor
universal applications
  • nominal pressure:0 ... 400 mbar up to 0 ... 600 bar
  • accuracy:0.5 % FSO
  • certificates: CE Ex
